Acupanel® Colour Concrete Grey Acoustic Wall Panels
Colour-wrapped acoustic slat panels in a cool concrete grey tone.
You need 0 panels to cover 0 m² (incl. 10% waste)
Trade pricing available. Join now
Order samples
Select the finishes you'd like to try
What you'll need
Specifications
- Slat Width
- 27mm
- Slat Spacing
- 13mm
- Panel Thickness
- 20mm
- Panel Width
- 600mm
- Panel Length
- 2000mm / 2400mm / 3000mm
- Material
- Wrapped colour finish on MDF with recycled acoustic felt
- Sound absorption (NRC)
- 0.75, on 45mm battens, measured to EN ISO 354
How to install
-
1
Measure
Measure your wall height and width. Calculate how many panels you need using our coverage calculator.
-
2
Cut
Cut panels to size using a mitre saw or circular saw. Mark cutouts for sockets from the back of the panel. Sand any cut edges lightly.
-
3
Sand
Lightly sand any cut edges with fine-grit paper. Removes rough fibres and gives a clean, finished look.
-
4
Mount
Apply construction adhesive to the back of each panel. Press firmly against the wall, starting from the bottom. Use panel pins for extra hold while the adhesive sets.
Description
Key Features Acupanel is the original acoustic slat wood panel. All stock held in our UK warehouse. Perfect for both residential and commercial environments. Backing felt material produced from recycled material. Quick and easy installation. Class-A superior sound absorption. Overview Acupanel is a beautifully designed strip decorative wall and ceiling panel which boasts high-quality acoustic properties. The panels can be easily applied to walls and ceilings, be it for domestic or commercial use. Modern styling personified in every way.
The colour Acupanel range is produced with a luxury quality, smooth veneer finish. Lamella strips with a clean, modern appearance are mounted onto a uniquely designed, recycled acoustic felt material. Fast and simple installation allows you to quickly transform any space.
As of the 26th May 2026, these panels now have a new and improved laminate finish. For details or assistance, please contact our Customer Service team.
Specification 240cm x 60cm
2400mm (H)
600mm (W)
19mm (D)
1.44m² Coverage
300cm x 60cm
3000mm (H)
600mm (W)
19mm (D)
1.8m² Coverage
Installation & Downloads The Acupanel range has been designed to be installed with ease. We recommend either screwing the panels straight into the wall, using the correct fixings, through the acoustic felt or if you are looking to increase the sound properties further, screwing them into batons. If installing on ceilings, the panels can be screwed straight into ceiling joists.
When cutting your panels, it's important to check where you are cutting in relation to the backing staples. If you cut the panels close to the staples, you may notice some slats lifting away from the backing where the panel has been cut. This is completely normal and is quickly rectified by adding additional staples through the backing felt or using a grab adhesive on the back of the slats.
Acupanel Technical Sheet Delivery The Acupanel range is fully stocked in our UK warehouse. We offer free delivery on our Acupanel range!
Can't Decide?
Try a Sample
Sample
Delivery and returns
Delivery options and timing vary by product. View the methods available at checkout.
30-day returns on all orders
Items must be unopened and in original packaging
Contact us to arrange a return
Notify me
What sets it apart
The colour you want. The quiet you need.
Each Acupanel® Concrete Grey panel pairs a top-surface laminate finish with a recycled acoustic felt core. The laminate carries a soft concrete-grey tone across the slat face, giving each wall a consistent, contemporary surface without grain variation. The colour is consistent, the surface softens light, and the acoustic core absorbs sound.
Built on 50 years of surface materials knowledge. The same precision engineering as our wood range, finished with a durable top-surface laminate. From residential spaces to commercial specification, the panel brings a quiet, architectural tone that painted finishes cannot match.
How it works
1
Measure
Measure your wall height and width. Calculate how many panels you need using our coverage calculator.
2
Cut
Cut panels to size using a mitre saw or circular saw. Mark cutouts for sockets from the back of the panel. Sand any cut edges lightly.
3
Sand
Lightly sand any cut edges with fine-grit paper. Removes rough fibres and gives a clean, finished look.
4
Mount
Apply construction adhesive to the back of each panel. Press firmly against the wall, starting from the bottom. Use panel pins for extra hold while the adhesive sets.
